HardKorr started with the best LED chips currently available on the market, from Lumileds. Forget the old argument between OSRAM and CREE, Lumileds LEDs are starting to appear in more and more high-end driving lights, and for good reason. They are incredibly bright, much more than anything else we’ve ever come across, and very efficient as well.
Why does this matter? Good question. Using LED chips with such high brightness means that our reflector engineers have been able to achieve the “holy grail” of driving lights: a true combination beam, as good as you’ll find in a light bar, without sacrificing forward distance.
They’re also CISPR15 compliant, meaning they have been independently tested to ensure they do not interfere with radio frequencies.
Combined with a tough, understated look, integrated daytime running lights (DRL) and strong 4mm 316 stainless steel brackets, they are the ultimate driving lights for keen adventurers, professional drivers and those who spend a lot of time on country roads.
Wiring Harnesss Included
HardKorr include a dual output wiring harness in the box with all BZR-X driving lights. This harness is suitable for use with 12V and 24V setups, as well as both positively and negatively switched vehicles. It complies with all ADR rules, and comes with H3 and H4 high beam piggyback adaptors.
The HardKorr Guarantee
All Hardkorr products are manufactured using the highest quality materials. They are confident that they are the most durable in the market and will give you many years of reliable service. HardKorr stand behind this product with a comprehensive 3-year Australian warranty.
Materials
- Housing: ADC12 aluminium with AkzoNobel® powder coating
- Bracket: 4mm 316 stainless steel with AkzoNobel® powder coating
- Lens: UV-coated Lexan® polycarbonate
Dimensions
- 175mm (w) x 190mm (h) x 75mm (d) including bracket
LED Details
- LED Manufacturer: Genuine Lumileds®
- Number of LEDs (each): 19 x 5w
- Total Lumens (pair): 22,588 effective lumens
- Lux (pair): 1 lux @ 1,150m
- Beam: Combination
Ratings
- Ingress Protection: IP68
- EMC Rating: CISPR 15 Class 3
- Impact Rating: IK08 (5J)
- Vibration Rating: IEC 60068-2-6 & ISO16750-1 (15G R.M.S. @ 24-2000Hz)
Electrical Specifications
- Operating Voltage: 10 – 30v DC
- Current (each): 7.7A @ 12V / 3.75A @ 24V
- Color Temperature: 6000K
- LED Lifespan: 50,000+ hours
Certifications
- CE, RoHS, RCM
Pack Contents
- 1x 95w LED driving light
- 1x 316 stainless steel mounting bracket
- 1x set security bolts & anti-vibration rubber base
- 1x 2-into-1 Deutsch adaptor cable
SKU | HKBZRX180-S |
---|---|
Barcode # | 9350466002065 |
Brand | HardKorr |
